Description
| Product model | 3500/32M 149986-02 |
| Manufacturer | Bently Nevada (a Baker Hughes company) |
| Product category | Enhanced Relay Output Module |
| Platform | 3500 Machinery Protection System |
| Number of channels | 4 independent logic channels |
| Relays per channel | 2 Form C (SPDT) electromechanical relays |
| Relay rating | 2 A @ 30 V DC; 1 A @ 125 V AC (resistive load) |
| Input source | Digital trip signals from 3500 monitor modules (e.g., 3500/25, /42, /45, /61) |
| Logic configuration | User-programmable via 3500 Rack Interface: 1oo1, 1oo2, 2oo2, 2oo3 per channel |
| Diagnostic features | Relay health monitoring, coil continuity test, LED status indicators |
| Mounting | Full-slot module in 3500 chassis (requires 3500/15 or /22 power supplies) |
| Operating temperature | 0°C to +65°C |
| Safety compliance | Designed to support SIL 2 applications per IEC 61508; compliant with API 670 |
Product Introduction
The Bently Nevada 3500/32M 149986-02 is an advanced relay output module engineered for the 3500 Machinery Protection System, delivering fail-safe, programmable shutdown and alarm signaling for critical rotating equipment. Unlike basic relay modules, the Bently Nevada 3500/32M 149986-02 provides four independent logic channels—each equipped with dual Form C relays—that can be configured to execute complex voting schemes based on inputs from vibration, position, speed, or temperature monitors within the 3500 rack.
Designed to meet the stringent requirements of API 670 for machinery protection, the Bently Nevada 3500/32M 149986-02 serves as the final control element between condition monitoring and plant safety systems. It translates digital trip commands from modules like the 3500/25 (Speed), 3500/42 (Proximitor Monitor), or 3500/61 (Temperature) into dry contact closures that interface directly with turbine emergency stop valves, motor starters, or DCS interlock circuits. Its enhanced architecture supports redundancy and fault tolerance, making it indispensable in oil & gas compressors, steam turbines, centrifugal pumps, and generator sets where unplanned trips carry severe operational and financial consequences.
Core Advantages and Technical Highlights
Flexible, application-specific logic per channel: Each of the four channels on the Bently Nevada 3500/32M 149986-02 can be independently programmed via the 3500 Rack Configuration Software to implement voting logic such as “1 out of 2” (1oo2) for redundant sensors or “2 out of 3” (2oo3) for high-integrity turbine trips. This eliminates the need for external hardwired logic panels, reducing system complexity and improving diagnostic coverage.
Dual-relay redundancy with health monitoring: The Bently Nevada 3500/32M 149986-02 features two physically separate relays per channel, enabling one to drive a DCS alarm while the other triggers a safety shutdown—ensuring functional separation per IEC 61511. Critically, the module continuously monitors relay coil integrity and contact status, reporting faults to the 3500 system before a failure compromises protection capability.
Certified for safety-critical service: Engineered to support SIL 2 applications, the Bently Nevada 3500/32M 149986-02 undergoes rigorous design validation per IEC 61508. Its electromechanical relays offer true galvanic isolation and are rated for millions of operations under load. Combined with API 670 compliance, this makes the module suitable for use in hazardous environments where regulatory audits demand documented reliability.
Seamless integration with legacy and modern 3500 systems: The Bently Nevada 3500/32M 149986-02 operates in any standard 3500 chassis with compatible power (3500/15 or /22) and communication modules (3500/22 or /92). It coexists with both analog and digital monitor cards, enabling phased upgrades without full system replacement—a key advantage for aging refineries or power plants extending asset life.
Typical Application Scenarios
The Bently Nevada 3500/32M 149986-02 is widely deployed in upstream and midstream oil & gas facilities, where it protects multi-million-dollar compressors and turbines from catastrophic failure. In a natural gas pipeline station, the Bently Nevada 3500/32M 149986-02 might receive overspeed signals from a 3500/25 and high-vibration alerts from a 3500/42, then execute a 2oo2 logic to close emergency shutdown valves—preventing rotor burst or fire. Its dual relays allow one contact to signal the local PLC while the other directly interrupts the turbine’s hydraulic trip solenoid.
In combined-cycle power plants, the Bently Nevada 3500/32M 149986-02 interfaces with generator step-up transformer cooling pumps, triggering alarms on bearing wear (via 3500/45) while maintaining separate trip paths to avoid nuisance shutdowns. Similarly, in petrochemical crackers, it enforces interlocks between lube oil pressure (3500/33) and shaft displacement (3500/42), using 1oo2 logic to balance availability and safety. Wherever machinery protection must be deterministic, auditable, and fail-safe, the Bently Nevada 3500/32M 149986-02 delivers industrial-grade reliability.
Related Model Recommendations
Related Model Recommendations- 3500/25 133442-01: Speed/vibration monitor—common input source for 3500/32M 149986-02 trip logic
- 3500/42 133440-01: 4-channel Proximitor monitor for radial vibration—feeds critical trip signals
- 3500/15: Standard power supply module required to operate the 149986-02 in a 3500 rack
- 3500/22: Enhanced communication module—enables configuration and diagnostics of the 3500/32M
- 3500/33 133444-01: 2-channel axial position monitor—often used in tandem with 149986-02 for thrust protection
- 3500/50 133450-01: Tachometer input module—provides speed reference for overspeed logic
- 3500/32 125744-01: Legacy non-enhanced relay module—lacks voting logic and dual relays of the 3500/32M
- 3500/92: Ethernet communication gateway—for remote access to 149986-02 status and configuration
Installation, Commissioning and Maintenance Instructions
Installation preparation: Before installing the Bently Nevada 3500/32M 149986-02, ensure the 3500 rack is powered down and all energy sources isolated. Confirm compatibility with existing power (3500/15 or /22) and communication modules. The module occupies one full slot and requires secure seating in the backplane—align carefully and press until fully latched. Field wiring should use shielded, stranded cable rated for relay loads, with terminals torqued to 0.5 N·m.
